The UC450 Series universal trap connector system with multiple choices for trap modules and multiple choices for connectors are used in steam systems where a simplified and economical maintenance program of steam traps is desired. These universal style quick replacement steam traps can be used on steam supply lines as well as for tracing and small process applications. They are commonly used in chemical plants, petrochemical refineries, paper mills and other industrial facilities.

Watson McDaniel Connector, Stainless Steel, 750 psi, 2.92 in L, 1 in Nominal, NPT Connection, 800 deg F, For Use With: Universal Quick-Change Trap Modules, UC450 Series

• Universal connector with two-bolt mounting allows for fast, easy replacement of trap module making it more cost effective than replacing conventional type steam traps
• Trap module can rotate 360 deg on the universal connector allowing any orientation during installation
• Compatible with other manufacturer's trap modules
• Without strainer

• Specification Sheet https://7100msci-stage.cimm2.com//ASSETS/DOCUMENTS/ITEMS/EN/Watson_McDaniel_UC450_12_N_Specification_Sheet.pdf
