Sharpe® SV54574002 VS545741/4
Sharpe® SV54574002 54574 2-Piece Ball Valve, 1/4 in Nominal, Thread End Style, 316 Stainless Steel Body, Standard Port, PTFE Softgoods
- Brand: Sharpe®
- Manufacturer:ASC Engineered Solutions
- MKSPN: VS545741/4
- MPN: SV54574002
- Min. Order Qty: 1
- Qty. Interval: 1
-
Login or Register for pricing
Sharpe® Ball Valve, 2-Piece, Series: 54574, 1/4 in Nominal, Thread End Style, 2000 psi CWP Pressure, Standard Port, 0.46 in Orifice, Lever Operated Actuator, 316 Stainless Steel Ball, 2-1/4 in Inlet to Outlet Length, 2.13 in Top to Inlet Center, 316 Stainless Steel Body, 316 Stainless Steel Stem and RTFE Seat Trim, PTFE Softgoods
| Actuator Type | : | Lever Handle |
| Ball Material | : | 316 Stainless Steel |
| Domestic/Import | : | Import |
| End Style | : | FNPT |
| Inlet to Outlet Length | : | 2-1/4 in |
| Item Type | : | Ball Valve-Threaded 2 Piece |
| Material | : | Carbon Steel |
| Nominal/Diameter Size | : | 1/4 in |
| Orifice Size | : | 0.46 |
| Port Type | : | Standard |
| Pressure Rating | : | 2000 psig CWP |
| Series | : | 54574 |
| Softgoods Material | : | PTFE |
| Temperature Rating | : | 0 to 450 deg f |
| Top to Inlet Center | : | 2.13 in |
| Trim Material | : | 316 Stainless Steel Stem and RTFE Seat |
| Type | : | 2-Piece |
Blow-out proof stem
